Lawn Tractor · 1999Unverified
Wheel Horse 17-44XL
Wheel Horse 17-44XL — XL Series · 17 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
17 hp
Weight
212 kg
Hover a source tag to verify
Overview
ManufacturerWheel Horse (a part of Toro)Reference
Lawn tractorReference
Original price was $2,899 in 2001Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
17HP Briggs & Stratton 501cc 1-cyl gasolineReference
Fuel tank6.6 LReference
Briggs & Stratton 312777Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement30.59 ciReference
Bore/Stroke90 x 78 mmReference
Power (gross)12.7 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TransmissionHydro-Gear 321-0650Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
Dimensions
Wheelbase120 cmReference
Weight212 kgReference
Front tire15x6.00-6Reference
Rear tire20x10.00-8Reference
44" mid-mount mower deckReference
bladeReference
Lawn/turf front15x6.00-6Reference
Lawn/turf rear20x10.00-8Reference
Length172 cmReference
Electrical
GroundnegativeReference
Battery CCA160Reference
Battery volts12Reference
Attachment overview
44" mid-mount mower deckReference
BladeReference
44" Mower deck
Typemid-mount ToroReference
Type3-bladeReference
Cutting width111 cmReference
Overall width139 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
