Lawn Tractor · 1989Unverified
Wheel Horse 208-4SB
Wheel Horse 208-4SB — 200 Series · 8 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
8 hp
Weight
209 kg
Hover a source tag to verify
Overview
ManufacturerWheel Horse (a part of Toro)Reference
Lawn tractorReference
Built in South Bend, Indiana, USAReference
Advertised as the 208-4SB Super Bagger the tractor came standard with a single-blade 30-inch mower deck.Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
8HP Briggs & Stratton 318cc 1-cyl gasolineReference
Fuel tank5.7 LReference
Briggs & Stratton 191707Reference
gasolineReference
1-cylinderReference
air-cooledReference
Displacement19.44 ciReference
Bore/Stroke76 x 70 mmReference
Power6.0 kWReference
Rated RPM3600Reference
Starter volts12Reference
Oil capacity1.1 LReference
Sparkplug gap0.762 mmReference
Point gap0.508 mmReference
Transmission
4-speed gearReference
TransmissionPeerless 920Reference
Typebelt-driven gearReference
Gears4 forward and 1 reverseReference
Dimensions
Wheelbase113 cmReference
Weight209 kgReference
Front tire13x5.00-6Reference
Rear tire16x6.50-8Reference
30" mid-mount mower deckReference
snowblowerReference
bladeReference
Lawn/turf front13x5.00-6Reference
Lawn/turf rear16x6.50-8Reference
Length154 cmReference
Width85 cmReference
Height92 cmReference
208-4SB Serial Number Location
Serial number decal on the left side of the rear fender deck, below the seat.Reference
208-4SB Serial Numbers
198942-08B401Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
30" mid-mount mower deckReference
SnowblowerReference
BladeReference
A two-bag rear grass collection system, 07-08BL01, was optional.Reference
30" Mower deck
Typemid-mount Wheel HorseReference
Type1-bladeReference
Cutting width76 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
