Lawn Tractor · 1990Unverified
Wheel Horse 210-H
Wheel Horse 210-H — 200 Series · 10 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
10 hp
Weight
208 kg
Hover a source tag to verify
Overview
ManufacturerWheel Horse (a part of Toro)Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
210-HhydrostaticReference
210-55-speedReference
Engine
10HP Briggs & Stratton 399cc 1-cyl gasolineReference
Fuel tank5.7 LReference
Briggs & Stratton 256707Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Original engine. The 256707 was used during the 1990 and 1991 model years.Reference
Displacement24.36 ciReference
Bore/Stroke87 x 67 mmReference
Power (gross)7.5 kWReference
StarterelectricReference
Starter volts12Reference
Sparkplug gap0.889 mmReference
Oil capacity1.4 LReference
Briggs & Stratton 257707Reference
The Briggs 257707 was introduced for the 1992 model year on the 210-H, model number 32-10BE03.Reference
Transmission
hydrostaticReference
TransmissionEaton 750Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
Oil capacity1.7 LReference
Oil typeSAE 20Reference
Oil changefill as neededReference
Dimensions
Wheelbase113 cmReference
Weight208 kgReference
Front tire15x6.00-6Reference
Rear tire18x9.50-8Reference
30" mid-mount mower deckReference
36" mid-mount mower deckReference
38" mid-mount mower deckReference
snowblowerReference
bladeReference
Lawn/turf front15x6.00-6Reference
Lawn/turf rear18x9.50-8Reference
Length154 cmReference
Width78 cmReference
Height (steering wheel)91 cmReference
Shipping weight208 kgReference
210-H Serial Numbers
Location:Serial number located below the seat on the rear fender. Model numbers in parenthesis.Reference
1990-unknown-Reference
19911000001 (32-10BE02)Reference
19922000001 (32-10BE03)Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps5Reference
Battery CCA160Reference
Battery volts12Reference
Attachment overview
30" mid-mount mower deckReference
36" mid-mount mower deckReference
38" mid-mount mower deckReference
SnowblowerReference
BladeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
