Lawn Tractor · 1994Unverified
Wheel Horse 264
Wheel Horse 264 — 260 Series · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Weight
510 to 521 pounds
Hover a source tag to verify
Overview
ManufacturerWheel Horse (a part of Toro)Reference
Garden tractorReference
The Toro Wheel Horse 264 carried several model codes: 72042 and 72062 For the 264-6, and 72043 and 72063 for the 264-H.Reference
Two-wheel driveReference
Manual steeringReference
Hydrostatic BrakesbandReference
Open operator station.Reference
Variants
264-6gearReference
264-HhydrostaticReference
LS35similar Ford modelReference
Engine
14HP Kohler 398cc 1-cyl gasolineReference
Fuel tank14.8 LReference
Kohler CV14SReference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement24.3 ciReference
Bore/Stroke87 x 67 mmReference
Power (gross)10.4 kWReference
StarterelectricReference
Starter volts12Reference
SparkplugChampion RC-12YCReference
Sparkplug gap1.016 mmReference
Oil capacity1.9 LReference
Oil change100 hReference
Transmission
hydrostaticReference
6-speed gearReference
Gear BrakesdiscReference
Gear Weight236 kgReference
TransmissionTuff Torq K-61AReference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
Oil capacity3.3 LReference
Oil typeSAE 10W-30Reference
Oil changefill as neededReference
TransmissionPeerless 820-024Reference
Typebelt-driven gearReference
Gears6 forward and 1 reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchelectricReference
Dimensions
Wheelbase125 cmReference
Weight510 to 521 poundsReference
Front tire16x6.50-8Reference
Rear tire23x9.50-12Reference
Lawn/turf front16x6.50-8Reference
Lawn/turf rear23x9.50-12Reference
Length175 cmReference
Width90 cmReference
Hydrostatic Weight231 kgReference
264 Serial Numbers
Location:Serial number decal on the rear fender deck, below the seat.Reference
19944900001Reference
19955900001Reference
19966900001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging amps15Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
