The Wheel Horse 269-H is a lawn tractor model with a rated output of 19 hp, placing it within the middle power range of its class. It was manufactured from 1996 to 1998. The 269-H is equipped with a 2-cylinder petrol air-cooled engine, which powers two-wheel drive via a hydrostatic transmission. Its listed weight is 254 kg, suitable for tasks up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
19 hp
Weight
254 kg
Catalogue coverage
Variants represented
2
Richest spec table
44 rows
Recorded power
19 hp
Recorded weight
254 kg
Transmissions
hydrostatic
Production years
1996-1998
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerWheel Horse (a part of Toro)Reference
Garden tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
19HP Kohler 624cc 2-cyl gasolineReference
Fuel tank14.8 LReference
Kohler CV19SReference
gasolineReference
2-cylinderReference
air-cooled vertical-shaft V-TwinReference
Displacement38.1 ciReference
Bore/Stroke77 x 67 mmReference
Power (gross)14.2 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TransmissionTuff Torq K-61AReference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
Oil capacity3.3 LReference
Oil typeSAE 10W-30Reference
Oil changefill as neededReference
Dimensions
Wheelbase125 cmReference
Weight254 kgReference
38" mid-mount mower deckReference
42" mid-mount mower deckReference
48" mid-mount mower deckReference
snowblowerReference
bladeReference
Length175 cmReference
Width90 cmReference
269-H Serial Numbers
Location:Serial number decal on the rear fender deck, below the seat.Reference
19966900001Reference
19977900001Reference
19988900001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
38" mid-mount mower deckReference
42" mid-mount mower deckReference
48" mid-mount mower deckReference
SnowblowerReference
BladeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
