Lawn Tractor · 1963Unverified

Wheel Horse 603

Name: Wheel Horse 603
Brand: Wheel Horse

Wheel Horse 603 · 6 hp. Reference specifications; pending source verification.

The Wheel Horse 603 is a lawn tractor rated at 6 hp — making it one of the more compact options in its class. The 603 was manufactured in 1963. Power comes from a 1-cylinder petrol air-cooled engine, driving through two-wheel drive with a 3-speed gearbox. Listed weight is 158 kg, and it is aimed at jobs of around up to 200 ac. Recorded specifications in UK and US units are listed below.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

6 hp

Weight

158 kg

Catalogue coverage

Variants represented

Richest spec table

38 rows

Recorded power

6 hp

Transmissions

3-speed gear

Production years

1963-1963

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerWheel HorseReference

Built in South Bend, Indiana, USAReference

Two-wheel driveReference

Manual steeringReference

Open operator station.Reference

Engine

6HP Lauson 221cc 1-cyl gasolineReference

Fuel tank3.8 LReference

LausonReference

gasolineReference

1-cylinderReference

air-cooled horizontal-shaftReference

Displacement13.53 ciReference

Bore/Stroke67 x 64 mmReference

Power4.5 kWReference

Starter typemanual recoilReference

Transmission

3-speed gearReference

TransmissionUni-DriveReference

Typebelt-driven gearReference

Gears3 forward and 1 reverseReference

Dimensions

Wheelbase104 cmReference

Weight158 kgReference

Front tire4.00x8Reference

Rear tire6.00x12Reference

32" mid-mount mower deckReference

36" mid-mount mower deckReference

snowblowerReference

bladeReference

Lawn/turf front4.00x8Reference

Lawn/turf rear6.00x12Reference

Length154 cmReference

Width76 cmReference

Height (steering wheel)92 cmReference

Height (hood)80 cmReference

Ground clearance18 cmReference

Attachment overview

32" mid-mount mower deckReference

36" mid-mount mower deckReference

SnowblowerReference

BladeReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
