Lawn Tractor · 1963Unverified
Wheel Horse 753
Wheel Horse 753 — Garden tractor · 7 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
7 hp
Weight
190 kg
Hover a source tag to verify
Overview
ManufacturerWheel HorseReference
Garden tractorReference
Built in South Bend, Indiana, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
7HP Kohler 277cc 1-cyl gasolineReference
Fuel tank3.8 LReference
Kohler K161SReference
gasolineReference
1-cylinderReference
air-cooled horizontal-shaftReference
Displacement16.94 ciReference
Bore/Stroke75 x 64 mmReference
Power5.2 kWReference
Rated RPM3600Reference
StarterelectricReference
Starter volts12Reference
Transmission
3-speed gearReference
TransmissionUni-DriveReference
Typebelt-driven gearReference
Gears3 forward and 1 reverseReference
Dimensions
Wheelbase104 cmReference
Weight190 kgReference
Front tire4.00x8Reference
Rear tire6.00x12Reference
32" mid-mount mower deckReference
36" mid-mount mower deckReference
snowblowerReference
bladeReference
Lawn/turf front4.00x8Reference
Lawn/turf rear6.00x12Reference
Length154 cmReference
Width81 cmReference
Height (steering wheel)92 cmReference
Height (hood)80 cmReference
Ground clearance18 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
32" mid-mount mower deckReference
36" mid-mount mower deckReference
SnowblowerReference
BladeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
