Lawn Tractor · 1992Unverified
Wheel Horse 824-Z
Wheel Horse 824-Z — Zero-turn mower · 24 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
453 kg
Hover a source tag to verify
Overview
ManufacturerWheel Horse (a part of Toro)Reference
Zero-turn mowerReference
Two-wheel driveReference
Power steeringReference
Open operator station.Reference
Engine
24HP Onan 978cc 2-cyl gasolineReference
Fuel tank22.7 LReference
Onan P224GReference
gasolineReference
2-cylinderReference
air-cooled horizontal-shaft horizontally-opposedReference
Displacement59.7 ciReference
Bore/Stroke90 x 76 mmReference
Power17.9 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TransmissionSundstrand BDU-10LReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchelectricReference
Dimensions
Wheelbase106 cmReference
Weight453 kgReference
Front tire13x5.00-6Reference
Rear tire22x11.00-8Reference
50" mid-mount mower deckReference
60" mid-mount mower deckReference
bladeReference
Lawn/turf front13x5.00-6Reference
Lawn/turf rear22x11.00-8Reference
Length182 cmReference
Width121 cmReference
Electrical
GroundnegativeReference
Battery CCA280Reference
Battery volts12Reference
Attachment overview
50" mid-mount mower deckReference
60" mid-mount mower deckReference
BladeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
