Lawn Tractor · 1964Unverified

Wheel Horse 854

Name: Wheel Horse 854
Brand: Wheel Horse

Wheel Horse 854 — Garden tractor · 8 hp. Reference specifications; pending source verification.

The Wheel Horse 854 is a lawn tractor model with a rated output of 8 hp — making it one of the more compact options in its class. This model was produced in 1964. It is powered by a 1-cylinder petrol air-cooled engine, driving through two-wheel drive with a 3-speed gearbox. Listed weight is 181 kg, and it is aimed at jobs of around up to 200 ac. Available dimensions and performance figures follow in both unit systems.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

8 hp

Weight

181 kg

Catalogue coverage

Variants represented

Richest spec table

44 rows

Recorded power

8 hp

Transmissions

3-speed gear

Production years

1964-1964

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerWheel HorseReference

Garden tractorReference

Built in South Bend, Indiana, USAReference

Two-wheel driveReference

Manual steeringReference

Open operator station.Reference

Engine

8HP Kohler 390cc 1-cyl gasolineReference

Fuel tank3.8 LReference

Kohler K181SReference

gasolineReference

1-cylinderReference

air-cooledReference

Displacement23.85 ciReference

Bore/Stroke83 x 73 mmReference

Power6.0 kWReference

Rated RPM3600Reference

Starter volts12Reference

Transmission

3-speed gearReference

TransmissionWheel Horse Uni-DriveReference

Typebelt-driven gearReference

Gears3 forward and 1 reverseReference

Dimensions

Wheelbase104 cmReference

Weight181 kgReference

Front tire4.00x8Reference

Rear tire6.00x12Reference

32" mid-mount mower deckReference

36" mid-mount mower deckReference

42" mid-mount mower deckReference

snowblowerReference

bladeReference

Lawn/turf front4.00x8Reference

Lawn/turf rear6.00x12Reference

Length152 cmReference

Width76 cmReference

Height (steering wheel)93 cmReference

Height (hood)81 cmReference

Ground clearance18 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

32" mid-mount mower deckReference

36" mid-mount mower deckReference

42" mid-mount mower deckReference

SnowblowerReference

BladeReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
