Tractor · 1976Unverified
White 2-70
White 2-70 — Field Boss Series · 71 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
71 hp
Max power
42.7 kW
Weight
7500 to 8630 pounds
Hover a source tag to verify
Overview
ManufacturerWhiteReference
Row-Crop tractorReference
Original price was $22,500 in 1982Reference
Two- or four-wheel driveReference
Power steeringReference
Independent dry disc brakesReference
ROPS with optional canopyReference
Engine
White 4.6L 6-cyl dieselReference
White 4.3L 6-cyl gasolineReference
Drawbar (tested)42.7 kWReference
WhiteReference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement4.6 LReference
Bore/Stroke98 x 102 mmReference
Air cleanerdryReference
Compression16:1Reference
Rated RPM2200Reference
Idle RPM800-2420Reference
Starter volts12Reference
Oil capacity8.8 LReference
Coolant capacity22.7 LReference
gasolineReference
Displacement4.3 LReference
Bore/Stroke95 x 102 mmReference
Compression8.5:1Reference
Power at rated engine speed52.7 kWReference
Max power42.7 kWReference
Transmission
6-speed unsynchronized gearReference
18-speed three-speed power shiftReference
Typeunsynchronized gearReference
Gears6 forward and 2 reverseReference
Clutch304.8mm cerametallic discReference
TransmissionHydraul-ShiftReference
Typethree-speed power shiftReference
Gears18 forward and 6 reverseReference
Six forward and two reverse gears with an over and under power shift for each gear.Reference
PTO & Hydraulics
PTO (claimed)52.2 kWReference
PTO (tested)52.7 kWReference
Hydraulic system18.9 LReference
Typeopen centerReference
Capacity18.9 LReference
Pressure141.3 barReference
Rear valves2Reference
Pump flow55.3 lpmReference
Rear TypeIIReference
Rear PTOindependentReference
Rear PTO Type540Reference
Rear PTO Type540/1000Reference
Capacities
Fuel104.1 LReference
Dimensions
Wheelbase267 cmReference
Weight7500 to 8630 poundsReference
Front tire7.50-16Reference
Rear tire16.9-38Reference
Ag front7.50-16Reference
Ag rear16.9-38Reference
Ag rear18.4-30Reference
Ag rear16.9-34Reference
Ag rear18.4-34Reference
Ag rear15.5-38Reference
Ag rear9.5-42Reference
Ag rear12.4-42Reference
Length408 cmReference
Width207 cmReference
Height (steering wheel)203 cmReference
Clearance (front axle)64 cmReference
Clearance (rear axle)69 cmReference
Clearance (drawbar)39 cmReference
Rear tread143 to 227 cmReference
Shipping3402 kgReference
Operating3914 kgReference
Ballasted4368 kgReference
White 2-70 attachments
front-end loaderReference
2-70 Serial Numbers
Location:Instrument panelReference
1976266173Reference
1977274543Reference
1978283917Reference
1979287528Reference
1980293819Reference
1981296246Reference
1982299887Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Attachment overview
White 1610 loaderReference
White 1730 QA loaderReference
Test results
Diesel 18-speed 2WDMay 18 - 28, 1976Link: Nebraska Tractor Test 1212 fileReference
PTO performanceReference
Fuel use23.1 l/hourReference
Drawbar performanceReference
Fuel use18.2 l/hourReference
Gear 4-under used for power test.Reference
Max pull3424 kgReference
Gear 1D used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
