Backhoe Loader · 1973Unverified

White 2-80-17

Name: White 2-80-17
Brand: White

White 2-80-17 — Backhoe loader tractor · 80 hp. Reference specifications; pending source verification.

The White 2-80-17 is a backhoe loader with a rated output of 80 hp — putting it around the middle of its class for power. The 2-80-17 was produced from 1973 to 1975. Under the hood is a 6-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a 6-speed gearbox. Listed weight is 7801 kg, and it is aimed at jobs of around up to 200 ac. See the table below for complete UK and US figures with sourcing.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

80 hp

Weight

7801 kg

Catalogue coverage

Variants represented

Richest spec table

68 rows

Recorded power

80 hp

Recorded weight

7801 kg

Transmissions

6-speed power shuttle

Production years

1973-1975

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerWhiteReference

Backhoe loader tractorReference

Power steeringReference

Disc brakesReference

Four-post ROPS.Reference

Variants

2-80-172WDReference

4-80-174WDReference

Engine

White 4.6L 6-cyl dieselReference

Fuel tank94.6 LReference

Engine (net)59.7 kWReference

White 283 DBReference

dieselReference

6-cylinderReference

liquid-cooledReference

Displacement4.6 LReference

Bore/Stroke98 x 102 mmReference

Power (net)59.7 kWReference

Air cleanerdryReference

Compression16:1Reference

Rated RPM2200Reference

Torque290.2 NmReference

Torque RPM1400Reference

StarterelectricReference

Starter volts12Reference

Oil capacity7.6 LReference

Coolant capacity18.9 LReference

Transmission

6-speed power shuttleReference

Typepower shuttleReference

Gears6 forward and reverseReference

Clutchwet discReference

Oil capacity30.3 LReference

Oil capacity10.4 LReference

PTO & Hydraulics

Type42Reference

Total flow177.9 lpmReference

Drawbaropen centerReference

Dimensions

Wheelbase218 cmReference

Weight7801 kgReference

Front tire11.00-16Reference

Rear tire16.9-28Reference

Industrial front11.00-16Reference

Industrial rear16.9-28Reference

Length807 cmReference

Height242 cmReference

Height (exhaust)251 cmReference

Height (backhoe)417 cmReference

Front tread172 cmReference

Rear tread181 cmReference

7801 kgReference

Max front axle5443 kgReference

Max rear axle6804 kgReference

Backhoe & Loader

Dig depth518 cmReference

Dump angle114 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps32Reference

Battery volts12Reference

Battery AH168Reference

Attachment overview

Front-end loaderReference

BackhoeReference

White 17 Backhoe

Backhoe typeWhite 17 BackhoeReference

Transport height417 cmReference

Digging depth518 cmReference

Reach from pivot655 cmReference

Loading height444 cmReference

Swing Arc180°Reference

Bucket force6032 kgReference

Dipperstick force3084 kgReference

Speeds

With 16.9x28 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
