Tractor · 1992Unverified
White 6065
White 6065 — Utility tractor · 63 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
63 hp
Weight
5400 to 6800 pounds
Hover a source tag to verify
Overview
DistributorWhite (a part of AGCO)Reference
ManufacturerSAMEReference
Utility tractorReference
Original price was $29,000 in 1999Reference
Two- or four-wheel driveReference
Final drivesinboard planetaryReference
Differential lockmechanical rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post ROPS. Cab optional.Reference
Engine
SLH 4.0L 4-cyl dieselReference
SLH 1000.4-WReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.0 LReference
Bore/Stroke105 x 116 mmReference
Fuel systemdirect injectionReference
Compression17:1Reference
Rated RPM2350Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed synchromeshReference
16-speed creeperReference
TypesynchromeshReference
Gears12 forward and reverseReference
Clutchhydraulic dry discReference
TypecreeperReference
Gears16 forward and reverseReference
PTO & Hydraulics
PTO (claimed)47.0 kWReference
Hydraulic system45.0 LReference
Typeopen centerReference
Capacity45.0 LReference
Pressure180.0 barReference
Valves2Reference
Pump flow41.6 lpmReference
ROPS Total flow56.4 lpmReference
Cab Total flow62.5 lpmReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear lift (at 24"/610mm)2249 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Capacities
ROPS Fuel61.3 LReference
Cab Fuel85.2 LReference
Dimensions
ROPS Wheelbase228 cmReference
Cab Wheelbase235 cmReference
Weight5400 to 6800 poundsReference
Front tire7.50-16Reference
Rear tire16.9R30Reference
Ag front7.50-16Reference
Ag rear16.9R30Reference
Length358 cmReference
ROPS Width185 cmReference
Cab Width195 cmReference
Height (ROPS)245 cmReference
Height (cab)248 cmReference
2WD ROPS Shipping weight2449 kgReference
4WD Cab Shipping weight3084 kgReference
White 6065 attachments
front-end loaderReference
6065 Serial Numbers
Location:Serial number plate on the tractor's console on the right side.Reference
1992001001 (ROPS)Reference
1993001122 (ROPS)Reference
1994001541 (ROPS)Reference
1992051001 (Cab)Reference
1993051041 (Cab)Reference
1994051055 (Cab)Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
White 678 loaderReference
White 678 SL loaderReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
