Tractor · 1993Unverified

White 6145

White 6145 — Workhorse 6100 Series · 143 hp. Reference specifications; pending source verification.

The White 6145 is a tractor with a rated power of 143 hp, positioning it at the higher end of its class. It was manufactured from 1993 to 1997. Key features include a 6-cylinder turbocharged diesel liquid-cooled engine, paired with four-wheel drive and a powershift transmission. Its operating weight ranges from 15400 to 16884 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
143 hp
Max power
93.5 kW
Weight
15400 to 16884 pounds

Catalogue coverage

Variants represented
2
Richest spec table
73 rows
Recorded power
143 hp
Recorded weight
6985 kg
Transmissions
18-speed full power shift
Production years
1993-1997
Verified variants
0

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerWhite (a part of AGCO)Reference
Row-Crop tractorReference
Built in Coldwater, Ohio, USAReference
Original price was $80,000 in 1997Reference
Two- or four-wheel driveReference
Power steeringReference
Differential hydraulic wet disc brakesReference
Cab standard with air-conditioning.Reference

Variants

614518-speed Funk power shiftReference
614432-speed QuadrashiftReference

Engine

CDC 5.9L 6-cyl dieselReference
Fuel tank253.6 LReference
Drawbar (tested)93.5 kWReference
CDC 6BTA5.9Reference
turbocharged aftercooled dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.9 LReference
Bore/Stroke102 x 120 mmReference
Fuel systemdirect injectionReference
Compression15.5:1Reference
Rated RPM2200Reference
Starter volts12Reference
Coolant capacity20.6 LReference
Power at rated engine speed106.4 kWReference
Max power93.5 kWReference

Transmission

18-speed full power shiftReference
ManufacturerFunk-DeereReference
Typefull power shiftReference
Gears18 forward and 9 reverseReference
Clutchhydraulic wet discReference

PTO & Hydraulics

PTO (claimed)105.9 kWReference
PTO (tested)106.4 kWReference
Typeclosed centerReference
Pressure158.6 barReference
Valves3Reference
Pump flow83.3 lpmReference
Rear TypeIII/IIReference
Controlelectronic lower-link draft sensingReference
Rear lift (at 24"/610mm)3129 kgReference
Rear lift (at 24"/610mm)3991 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Power at rated PTO speed105.2 kWReference

Dimensions

Wheelbase269 cmReference
Weight15400 to 16884 poundsReference
Front tire10.00-16Reference
Rear tire18.4R38DReference
Ag front10.00-16Reference
Ag rear18.4R38DReference
Length456 cmReference
Height300 cmReference
Shipping weight6985 kgReference
Operating weight7658 kgReference
Bar rear axle2489 mmReference
Bar rear axle2921 mmReference

6145 Serial Numbers

1993640001Reference
1994641001Reference
1995641501Reference
1996642301Reference
1997642350Reference
FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference

Test results

Diesel 18-speed 4WDApril 25 - May 6, 1994Link: OCED Tractor Test 1677 fileReference
PTO performanceReference
Fuel use32.6 l/hourReference
Fuel use30.7 l/hourReference
Drawbar performanceReference
Gear 7 used for power test.Reference
Max pull8805 kgReference
Gear 4 used for pull test.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
