Tractor · 1994Unverified
White 6215
White 6215 — Workhorse 6100 Series · 215 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
215 hp
Max power
184.8 kW
Weight
17300 to 19310 pounds
Hover a source tag to verify
Overview
ManufacturerWhite (a part of AGCO)Reference
Row-Crop tractorReference
Built in Coldwater, Ohio, USAReference
Original price was $120,000 in 1999Reference
Four-wheel driveReference
Power steeringReference
Differential hydraulic wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
CDC-Cummins 8.3L 6-cyl dieselReference
Fuel tank344.4 LReference
Drawbar (tested)138.4 kWReference
CDC-Cummins 6CTA8.3Reference
turbocharged intercooled dieselReference
6-cylinderReference
liquid-cooledReference
Displacement8.3 LReference
Bore/Stroke114 x 135 mmReference
Fuel systemdirect injectionReference
Air cleanerdual paper elementsReference
Compression16.5:1Reference
Rated RPM2200Reference
Starter volts12Reference
Max power184.8 kWReference
Power at rated engine speed160.7 kWReference
Max power138.4 kWReference
Transmission
18-speed full power shiftReference
ManufacturerFunk-DeereReference
Typefull power shiftReference
Gears18 forward and 9 reverseReference
Clutchhydraulic wet discReference
PTO & Hydraulics
PTO (claimed)160.3 kWReference
PTO (tested)184.8 kWReference
Typeclosed centerReference
Pressure193.1 barReference
Valves3Reference
Pump flow98.4 lpmReference
Rear TypeIII/IIReference
Controlelectronic lower-link draft sensingReference
Rear lift (at 24"/610mm)6350 kgReference
Rear PTOindependentReference
Rear PTO Type1000Reference
Power at rated PTO speed172.0 kWReference
Dimensions
Wheelbase287 cmReference
Weight17300 to 19310 poundsReference
Front tire16.9R28Reference
Rear tire20.8R38DReference
Ag front16.9R28Reference
Ag rear20.8R38DReference
Length479 cmReference
Height302 cmReference
Bar rear axle2921 mmReference
Shipping7847 kgReference
Operating8759 kgReference
Ballasted11584 kgReference
6215 Serial Numbers
1994601001Reference
1995601501Reference
1996602301Reference
1997602359Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Test results
Diesel 18-speed 4WDOctober 25 - November 7, 1996Link: OCED Tractor Test 1719 fileReference
PTO performanceReference
Fuel use55.3 l/hourReference
Fuel use53.4 l/hourReference
Fuel use54.5 l/hourReference
Drawbar performanceReference
Gear 11 used for power test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
