Tractor · 1998Unverified

White 6410

Name: White 6410
Brand: White

White 6410 — Utility tractor · 70 hp. Reference specifications; pending source verification.

The White 6410 is a tractor with a rated power of 70 hp, a mid-range figure for its class. Manufactured from 1998 to 2001, the 6410 features a 4-cylinder turbocharged diesel liquid-cooled engine, paired with a 12-speed gearbox and four-wheel drive. Its operating weight ranges from 7870 to 8650 pounds. This model is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

70 hp

Max power

56.1 kW

Weight

7870 to 8650 pounds

Catalogue coverage

Variants represented

Richest spec table

81 rows

Recorded power

70 hp

Recorded weight

3569 kg

Transmissions

12-speed partially synchronized

Production years

1998-2001

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerWhite (a part of AGCO)Reference

Utility tractorReference

Built in Beauvais, FranceReference

Original price was $33,000 in 1999Reference

Two- or four-wheel driveReference

Final drivesoutboard planetaryReference

Differential lockelectro-hydraulic front and rearReference

Power steeringReference

Hydraulic wet disc brakesReference

Two-post folding ROPS. Cab optional with air-conditioning. FieldStar readyReference

Variants

8745similar AGCO Allis modelReference

Engine

Cummins 3.9L 4-cyl dieselReference

ROPS Fuel tank126.8 LReference

Cab Fuel tank128.7 LReference

Cummins B3.9TReference

turbocharged dieselReference

4-cylinderReference

liquid-cooled inlineReference

Displacement3.9 LReference

Bore/Stroke102 x 120 mmReference

Compression17:1Reference

Rated RPM2200Reference

Starter volts12Reference

Max power56.1 kWReference

Power at rated engine speed52.5 kWReference

Transmission

12-speed partially synchronizedReference

12-speed synchronized shuttleReference

24-speed power shuttleReference

Typepartially synchronizedReference

Gears12 forward and 4 reverseReference

Clutchcerametallic dry discReference

Three gears, plus reverse in two ranges with a two-speed synchronized range split.Reference

Typesynchronized shuttleReference

Gears12 forward and reverseReference

Four gears in three ranges with synchronized shuttle.Reference

Typepower shuttleReference

Gears24 forward and reverseReference

PTO & Hydraulics

PTO (claimed)52.2 kWReference

PTO (tested)56.1 kWReference

Typeopen centerReference

Pressure210.0 barReference

Valves2Reference

Pump flow29.9 lpmReference

Pump flow37.9 lpmReference

Total flow97.7 lpmReference

Steering flow29.9 lpmReference

Rear TypeIIReference

Rear lift (at 24"/610mm)1859 kgReference

Rear lift (at 24"/610mm)2812 kgReference

Rear PTOindependentReference

Clutchwet discReference

Rear PTO Type540/1000 (1.375)Reference

Engine RPM540@1900Reference

Engine RPM1000@2000Reference

Power at rated PTO speed55.8 kWReference

Dimensions

Wheelbase251 cmReference

Weight7870 to 8650 poundsReference

Front tire9.5L-15Reference

Rear tire13.6R38Reference

Ag front9.5L-15Reference

Ag rear13.6R38Reference

Length419 cmReference

Width210 cmReference

Height (cab)261 cmReference

2WD ROPS Shipping weight3569 kgReference

4WD Cab Shipping weight3923 kgReference

Flange rear axleReference

White 6410 attachments

front-end loaderReference

6410 Serial Numbers

1998G01001Reference

1999H01001Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

White 675 loaderReference

White 678 loaderReference

White 678 SL loaderReference

Test results

Diesel 12-speed 4WDMarch 16 - 17, 2000Link: Nebraska Tractor Test 1769 fileReference

PTO performanceReference

Fuel use17.4 l/hourReference

Fuel use18.5 l/hourReference

Fuel use18.2 l/hourReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
