Tractor · 1998Unverified
White 6410
White 6410 — Utility tractor · 70 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
70 hp
Max power
56.1 kW
Weight
7870 to 8650 pounds
Hover a source tag to verify
Overview
ManufacturerWhite (a part of AGCO)Reference
Utility tractorReference
Built in Beauvais, FranceReference
Original price was $33,000 in 1999Reference
Two- or four-wheel driveReference
Final drivesoutboard planetaryReference
Differential lockelectro-hydraulic front and rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post folding ROPS. Cab optional with air-conditioning. FieldStar readyReference
Variants
8745similar AGCO Allis modelReference
Engine
Cummins 3.9L 4-cyl dieselReference
ROPS Fuel tank126.8 LReference
Cab Fuel tank128.7 LReference
Cummins B3.9TReference
turbocharged dieselReference
4-cylinderReference
liquid-cooled inlineReference
Displacement3.9 LReference
Bore/Stroke102 x 120 mmReference
Compression17:1Reference
Rated RPM2200Reference
Starter volts12Reference
Max power56.1 kWReference
Power at rated engine speed52.5 kWReference
Transmission
12-speed partially synchronizedReference
12-speed synchronized shuttleReference
24-speed power shuttleReference
Typepartially synchronizedReference
Gears12 forward and 4 reverseReference
Clutchcerametallic dry discReference
Three gears, plus reverse in two ranges with a two-speed synchronized range split.Reference
Typesynchronized shuttleReference
Gears12 forward and reverseReference
Four gears in three ranges with synchronized shuttle.Reference
Typepower shuttleReference
Gears24 forward and reverseReference
PTO & Hydraulics
PTO (claimed)52.2 kWReference
PTO (tested)56.1 kWReference
Typeopen centerReference
Pressure210.0 barReference
Valves2Reference
Pump flow29.9 lpmReference
Pump flow37.9 lpmReference
Total flow97.7 lpmReference
Steering flow29.9 lpmReference
Rear TypeIIReference
Rear lift (at 24"/610mm)1859 kgReference
Rear lift (at 24"/610mm)2812 kgReference
Rear PTOindependentReference
Clutchwet discReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@1900Reference
Engine RPM1000@2000Reference
Power at rated PTO speed55.8 kWReference
Dimensions
Wheelbase251 cmReference
Weight7870 to 8650 poundsReference
Front tire9.5L-15Reference
Rear tire13.6R38Reference
Ag front9.5L-15Reference
Ag rear13.6R38Reference
Length419 cmReference
Width210 cmReference
Height (cab)261 cmReference
2WD ROPS Shipping weight3569 kgReference
4WD Cab Shipping weight3923 kgReference
Flange rear axleReference
White 6410 attachments
front-end loaderReference
6410 Serial Numbers
1998G01001Reference
1999H01001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
White 675 loaderReference
White 678 loaderReference
White 678 SL loaderReference
Test results
Diesel 12-speed 4WDMarch 16 - 17, 2000Link: Nebraska Tractor Test 1769 fileReference
PTO performanceReference
Fuel use17.4 l/hourReference
Fuel use18.5 l/hourReference
Fuel use18.2 l/hourReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
