Tractor · 1998Unverified

White 6510

Name: White 6510
Brand: White

White 6510 — Utility tractor · 85 hp. Reference specifications; pending source verification.

The White 6510 is a tractor with a rated output of 85 hp, positioning it in the middle of its class for power. It was manufactured from 1998 to 2001. The tractor is equipped with a 4-cylinder turbocharged diesel liquid-cooled engine, which drives through a four-wheel drive system and a 12-speed gearbox. Its listed weight ranges from 7870 to 8650 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

85 hp

Max power

65.6 kW

Weight

7870 to 8650 pounds

Catalogue coverage

Variants represented

Richest spec table

81 rows

Recorded power

85 hp

Recorded weight

3569 kg

Transmissions

12-speed partially synchronized

Production years

1998-2001

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerWhite (a part of AGCO)Reference

Utility tractorReference

Built in Beauvais, FranceReference

Original price was $36,000 in 1999Reference

Two- or four-wheel driveReference

Final drivesoutboard planetaryReference

Differential lockelectro-hydraulic front and rearReference

Power steeringReference

Hydraulic wet disc brakesReference

Two-post folding ROPS. Cab optional with air-conditioning. FieldStar readyReference

Variants

8765similar AGCO Allis modelReference

Engine

Cummins 3.9L 4-cyl dieselReference

ROPS Fuel tank126.8 LReference

Cab Fuel tank128.7 LReference

Cummins B3.9TReference

turbocharged dieselReference

4-cylinderReference

liquid-cooled inlineReference

Displacement3.9 LReference

Bore/Stroke102 x 120 mmReference

Compression17:1Reference

Rated RPM2200Reference

Starter volts12Reference

Max power65.6 kWReference

Power at rated engine speed63.7 kWReference

Transmission

12-speed partially synchronizedReference

12-speed synchronized shuttleReference

24-speed power shuttleReference

Typepartially synchronizedReference

Gears12 forward and 4 reverseReference

Clutchcerametallic dry discReference

Three gears, plus reverse in two ranges with a two-speed synchronized range split.Reference

Typesynchronized shuttleReference

Gears12 forward and reverseReference

Four gears in three ranges with synchronized shuttle.Reference

Typepower shuttleReference

Gears24 forward and reverseReference

PTO & Hydraulics

PTO (claimed)63.4 kWReference

PTO (tested)65.6 kWReference

Typeopen centerReference

Pressure210.0 barReference

Valves2Reference

Pump flow29.9 lpmReference

Pump flow37.9 lpmReference

Total flow97.7 lpmReference

Steering flow29.9 lpmReference

Rear TypeIIReference

Rear lift (at 24"/610mm)1859 kgReference

Rear lift (at 24"/610mm)2812 kgReference

Rear PTOindependentReference

Clutchwet discReference

Rear PTO Type540/1000 (1.375)Reference

Engine RPM540@1900Reference

Engine RPM1000@2000Reference

Power at rated PTO speed65.5 kWReference

Dimensions

Wheelbase251 cmReference

Weight7870 to 8650 poundsReference

Front tire9.5L-15Reference

Rear tire13.6R38Reference

Ag front9.5L-15Reference

Ag rear13.6R38Reference

Length419 cmReference

Width210 cmReference

Height (cab)261 cmReference

2WD ROPS Shipping weight3569 kgReference

4WD Cab Shipping weight3923 kgReference

Flange rear axleReference

White 6510 attachments

front-end loaderReference

6510 Serial Numbers

1998G01001Reference

1999H01001Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

White 675 loaderReference

White 678 loaderReference

White 678 SL loaderReference

Test results

Diesel 12-speed 4WDSeptember 14 - 23, 1999Link: Nebraska Tractor Test 1762 fileReference

PTO performanceReference

Fuel use19.7 l/hourReference

Fuel use21.2 l/hourReference

Fuel use20.4 l/hourReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
