Tractor · 1998Unverified
White 8410
White 8410 — Row-Crop tractor · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Max power
116.3 kW
Weight
15500 to 16715 pounds
Hover a source tag to verify
Overview
ManufacturerWhite (a part of AGCO)Reference
Row-Crop tractorReference
FactoriesColdwater, Ohio, USAReference
FactoriesBeauvais, FranceReference
Original price was $80,000 in 1999Reference
Two- or four-wheel driveReference
Power steeringReference
Differential hydraulic wet disc brakesReference
Cab standard.Reference
Variants
9745similar AGCO Allis modelReference
Engine
Cummins 5.9L 6-cyl dieselReference
Fuel tank378.5 LReference
Drawbar (tested)95.1 kWReference
CumminsReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.9 LReference
Bore/Stroke102 x 120 mmReference
Compression17.4:1Reference
Rated RPM2200Reference
Starter volts12Reference
Max power116.3 kWReference
Power at rated engine speed10.6 kWReference
Max power95.1 kWReference
Transmission
32-speed partial power shiftReference
18-speed full power shiftReference
TransmissionQuadrashiftReference
Typepartial power shiftReference
Gears32 forward and reverseReference
ManufacturerFunk-DeereReference
Typefull power shiftReference
Gears18 forward and 6 reverseReference
Clutchelectro-hydraulic wet discReference
PTO & Hydraulics
PTO (claimed)108.1 kWReference
PTO (tested)116.3 kWReference
Typeclosed centerReference
Valves3Reference
Pump flow106.0 lpmReference
Rear TypeII/IIINReference
Rear lift4717 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540@1990Reference
Engine RPM1000@2100Reference
Power at rated PTO speed114.3 kWReference
Dimensions
Wheelbase276 cmReference
Weight15500 to 16715 poundsReference
Front tire11.00-16Reference
Rear tire18.4R38Reference
Ag front11.00-16Reference
Ag rear18.4R38Reference
Length434 cmReference
Width249 cmReference
Height (cab)287 cmReference
Front tread153 to 224 cmReference
Rear tread157 to 273 cmReference
Shipping7030 kgReference
Operating7581 kgReference
Ballasted8554 kgReference
White 8410 attachments
front-end loaderReference
8410 Serial Numbers
1998G001001Reference
1999H001001Reference
2000J001001Reference
2001K001001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
White 688 loaderReference
White 688 SL loaderReference
Test results
Diesel 18-speed 4WDSeptember 22 - October 8, 1998Link: OCED Tractor Test 1753 fileReference
PTO performanceReference
Fuel use32.6 l/hourReference
Fuel use3.0 l/hourReference
Fuel use33.3 l/hourReference
Drawbar performanceReference
Gear 10 used for power test.Reference
Max pull8181 kgReference
Gear 4 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
