Tractor · 1986Unverified
White Field Boss 16
White Field Boss 16 — Compact Utility tractor · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Weight
1100 to 1188 pounds
Hover a source tag to verify
Overview
DistributorWhiteReference
ManufacturerIsekiReference
Compact Utility tractorReference
Original price was $7,400 in 1988Reference
Two- or four-wheel driveReference
Differential lockmechanical rearReference
SteeringmanualReference
Mechanical dry internal expanding brakesReference
2-post ROPS. Canopy optional.Reference
Variants
TX2160similar Iseki modelReference
Engine
Mitsubishi 0.8L 3-cyl dieselReference
Fuel tank12.1 LReference
Engine11.9 kWReference
Mitsubishi K3BReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement0.8 LReference
Bore/Stroke68 x 78 mmReference
Power11.9 kWReference
Pre-heatingglow plugsReference
Pre-heatingcoolant heaterReference
Compression23:1Reference
Rated RPM2600Reference
Starter volts12Reference
Transmission
6-speed gearReference
hydrostaticReference
TypegearReference
Gears6 forward and 2 reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
PTO (claimed)10.4 kWReference
TypeliveReference
Pressure137.2 barReference
Total flow9.8 lpmReference
Rear TypeIReference
Rear PTOtransmissionReference
Rear PTO Type540 (1.375)Reference
Engine RPM454@2600Reference
Engine RPM724@2600Reference
Engine RPM1185@2600Reference
Front PTO Type2600Reference
Dimensions
Wheelbase128 cmReference
Weight1100 to 1188 poundsReference
Front tire4.00-12Reference
Rear tire8.00-18Reference
Weight117 kgReference
Ag front4.00-12 (2WD)Reference
Ag front5.00-12 (4WD)Reference
Ag rear8.00-18Reference
Lawn/turf front20-8.0-10Reference
Lawn/turf rear29-12.50-15Reference
2WD Length198 cmReference
4WD Length199 cmReference
Width112 cmReference
Height (exhaust)169 cmReference
2WD Shipping weight498 kgReference
4WD Shipping weight538 kgReference
2WD Front tread70 cmReference
4WD Front tread76 cmReference
Rear tread77 to 89 cmReference
White Field Boss 16 attachments
48" mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
Field Boss 16 Serial Numbers
Location:Tractor frame on front-leftReference
1986TX2160T002314 (2WD)Reference
1987TX2160T002393 (2WD)Reference
1986TX2160F014422 (4WD)Reference
1987TX2160F014660 (4WD)Reference
1987TX2160TH002690 (2WD Hydro)Reference
1988TX2310FH016528 (4WD Hydro)Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps35Reference
Battery volts12Reference
Attachment overview
48" mid-mount mower deckReference
SnowblowerReference
BladeReference
White 1025QA loaderReference
White 1135 QA loaderReference
Several attachments were listed for the Field Boss 16 tractor. Mowers included mid or rear mount 48-inch finishing mowers, 50-inch flail mower, and 42 or 48 inch rotary cutters. PTO-driven tillers were available in 42 and 48 inch widths. A 5-foot rear blade and 4.5-foot box scraper were listed.Reference
48" Mower deck
Typemid-mount White M215Reference
Type3-blade with hydraulic liftReference
Cutting width121 cmReference
DriveshaftReference
Cut height2 to 12 cmReference
Speeds
With 8.00-18 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
