Wingin 554
Wingin 554 — Jinma built · 55 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
55 hp
Weight
2163 kg
Hover a source tag to verify
Overview
DistributorWinginReference
ManufacturerJinmaReference
Built in ChinaReference
Four-wheel driveReference
Engine
3.5L 4-cyl dieselReference
Engine41.0 kWReference
SL4105BTReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.5 LReference
Bore/Stroke100 x 110 mmReference
Power41.0 kWReference
Rated RPM2300Reference
Transmission
6-speedReference
8-speedReference
Gears6 forward and 2 reverseReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
Rear PTO Type540/720/1000Reference
Dimensions
Wheelbase207 cmReference
Weight2163 kgReference
Front tire8.3-20Reference
Rear tire12.4-28Reference
Ag front8.3-20Reference
Ag rear12.4-28Reference
Length395 cmReference
Width162 cmReference
Height248 cmReference
Ground clearance32 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
