The Wingin 554 is a tractor model with a rated output of 55 hp — making it one of the more compact options in its class. Power comes from a 4-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a 6-speed gearbox. Listed weight is 2163 kg, and it is aimed at jobs of around up to 200 ac. The available specification table below shows both UK and US units.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
55 hp
Weight
2163 kg
Catalogue coverage
Variants represented
2
Richest spec table
29 rows
Recorded power
55 hp
Recorded weight
2163 kg
Transmissions
6-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorWinginReference
ManufacturerJinmaReference
Built in ChinaReference
Four-wheel driveReference
Engine
3.5L 4-cyl dieselReference
Engine41.0 kWReference
SL4105BTReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.5 LReference
Bore/Stroke100 x 110 mmReference
Power41.0 kWReference
Rated RPM2300Reference
Transmission
6-speedReference
8-speedReference
Gears6 forward and 2 reverseReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
Rear PTO Type540/720/1000Reference
Dimensions
Wheelbase207 cmReference
Weight2163 kgReference
Front tire8.3-20Reference
Rear tire12.4-28Reference
Ag front8.3-20Reference
Ag rear12.4-28Reference
Length395 cmReference
Width162 cmReference
Height248 cmReference
Ground clearance32 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
