The Wisconsin Tractor 22-40 is a model rated at 22 horsepower, positioning it at the lower end of its class. Produced from 1918 to 1923, this tractor features a 4-cylinder petrol liquid-cooled engine, coupled with two-wheel drive and a 2-speed gearbox. Its capabilities extend to operations of up to 200 acres. Specific details are provided in the accompanying table.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
22 hp
Catalogue coverage
Variants represented
2
Richest spec table
21 rows
Recorded power
22 hp
Transmissions
2-speed gear
Production years
1918-1923
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerWisconsin TractorReference
Standard-tread tractorReference
Built in Sauk City, Wisconsin, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
Climax 10.9L 4-cyl gasolineReference
Drawbar (claimed)16.4 kWReference
Belt (claimed)29.8 kWReference
ClimaxReference
gasolineReference
4-cylinderReference
liquid-cooled inlineReference
Displacement10.9 LReference
Bore/Stroke140 x 178 mmReference
Rated RPM800Reference
Starter typehand-crankReference
Transmission
2-speed gearReference
TypegearReference
Gears2 forward and 1 reverseReference
22-40 Serial Number Location
Serial number plate on the right side of tractor's frame.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
