Lawn Tractor · 2000Unverified
Woods 6170
Woods 6170 — Front-mount mower · 18 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
18 hp
Weight
397 kg
Hover a source tag to verify
Overview
ManufacturerWoodsReference
Front-mount mowerReference
Two-wheel driveReference
Power steeringReference
Open operator station.Reference
Engine
18HP Vanguard 569cc 2-cyl gasolineReference
Fuel tank15.1 LReference
Vanguard 350447Reference
gasolineReference
2-cylinderReference
air-cooled horizontal-shaft V-TwinReference
Displacement34.75 ciReference
Bore/Stroke72 x 70 mmReference
Power (gross)13.4 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
Dimensions
Weight397 kgReference
Woods 6170 attachments
48" front-mount mower deckReference
Electrical
GroundnegativeReference
Battery volts12Reference
48" Mower deck
Typefront-mount WoodsReference
Type3-bladeReference
Cutting width121 cmReference
Cut height2 to 10 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
