Lawn Tractor · 1996Unverified
Woods 6210
Woods 6210 — Front-mount mower · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Weight
313 kg
Hover a source tag to verify
Overview
ManufacturerWoodsReference
Front-mount mowerReference
Two-wheel driveReference
Power steeringReference
Open operator station.Reference
Engine
20HP Kawasaki 617cc 2-cyl gasolineReference
Fuel tank15.1 LReference
Fuel tank30.3 LReference
Kawasaki FD620Reference
gasolineReference
2-cylinderReference
liquid-cooled horizontal-shaft V-TwinReference
Displacement37.65 ciReference
Bore/Stroke76 x 68 mmReference
Power (gross)14.9 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Front PTOindependentReference
ClutchelectricReference
Dimensions
Weight313 kgReference
Front tire20x10.00-8Reference
Rear tire13x5.00-6Reference
Lawn/turf front20x10.00-8Reference
Lawn/turf rear13x5.00-6Reference
Length287 cmReference
Height114 cmReference
Woods 6210 attachments
48" front-mount mower deckReference
52" front-mount mower deckReference
61" front-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
48" front-mount mower deckReference
52" front-mount mower deckReference
61" front-mount mower deckReference
SnowblowerReference
BladeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
