The XTZ T-012D is a tractor with an approximate power rating of 13 hp, positioning it at the lighter end of its class. It features a 3-cylinder diesel liquid-cooled engine and two-wheel drive with a 4-speed gearbox. The operating weight of the XTZ T-012D is 742 kg, and it is suited for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
13 hp
Weight
742 kg
Catalogue coverage
Variants represented
2
Richest spec table
32 rows
Recorded power
13 hp
Recorded weight
742 kg
Transmissions
4-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerXTZReference
Compact Utility tractorReference
Built in Kharkiv, UkraineReference
Two-wheel driveReference
Open operator station. Two-post ROPS available.Reference
Engine
Perkins 0.6L 3-cyl dieselReference
Fuel tank20.8 LReference
Engine9.3 kWReference
Perkins 103-06Reference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement0.6 LReference
Bore/Stroke64 x 64 mmReference
Power9.3 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
4-speedReference
Gears4 forward and 2 reverseReference
PTO & Hydraulics
Rear PTOindependentReference
Rear PTO Type1000Reference
Dimensions
Wheelbase104 cmReference
Weight742 kgReference
Front tire4.50-10.00Reference
Rear tire5.50-16.00Reference
Ag front4.50-10.00Reference
Ag rear5.50-16.00Reference
Length191 cmReference
Width96 cmReference
Height134 cmReference
Ground clearance29 cmReference
Rear tread70 to 89 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
