The XTZ XTZ-1410 is a tractor with a rated power of 14 hp, which places it at the lighter end of its class. Power comes from a diesel air-cooled engine, paired with two-wheel drive with a 4-speed gearbox. It has a listed operating weight of 800 kg, and it suits operations of up to 200 ac. The available specification table below shows both UK and US units.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Weight
800 kg
Catalogue coverage
Variants represented
2
Richest spec table
29 rows
Recorded power
14 hp
Recorded weight
800 kg
Transmissions
4-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerXTZReference
Compact Utility tractorReference
Built in Kharkiv, UkraineReference
Two-wheel driveReference
Open operator station. Two-post ROPS available.Reference
Engine
ZIM dieselReference
Fuel tank20.8 LReference
Engine10.3 kWReference
ZIMReference
dieselReference
air-cooledReference
Power10.3 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
4-speedReference
Gears4 forward and 2 reverseReference
PTO & Hydraulics
Rear PTOindependentReference
Rear PTO Type1000Reference
Dimensions
Wheelbase104 cmReference
Weight800 kgReference
Front tire6.50/70-10.00Reference
Rear tire210/80R16Reference
Ag front6.50/70-10.00Reference
Ag rear210/80R16Reference
Length191 cmReference
Width96 cmReference
Height134 cmReference
Ground clearance29 cmReference
Rear tread74 to 94 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
