Tractor · Unverified

XTZ XTZ-17022

Name: XTZ XTZ-17022
Brand: XTZ

XTZ XTZ-17022 — Four-wheel Drive (4WD) tractor · 180 hp. Reference specifications; pending source verification.

The XTZ XTZ-17022 is a tractor model with a power output of 180 hp, categorising it among higher-powered machines in its class. It is equipped with a 6-cylinder diesel liquid-cooled engine, which is connected to a 12-speed gearbox and powers four-wheel drive. The listed weight of the XTZ-17022 is 8700 kg, and it is designed for tasks covering approximately 600–1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

180 hp

Weight

8700 kg

Catalogue coverage

Variants represented

Richest spec table

38 rows

Recorded power

180 hp

Recorded weight

8700 kg

Transmissions

12-speed

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerXTZReference

Four-wheel Drive (4WD) tractorReference

Built in Kharkiv, UkraineReference

Four-wheel driveReference

Final drivesplanetaryReference

Articulated power steeringReference

Pneumatic drum brakesReference

Cab standard, air-conditioning available.Reference

Engine

Deutz 7.1L 6-cyl dieselReference

Fuel tank430.0 LReference

Engine134.2 kWReference

Deutz BF6M1013EReference

dieselReference

6-cylinderReference

liquid-cooled inlineReference

Displacement7.1 LReference

Bore/Stroke108 x 140 mmReference

Power134.2 kWReference

Rated RPM2200Reference

Starter typeelectricReference

Transmission

12-speedReference

Gears12 forward and 4 reverseReference

Clutchdry discReference

Four gears in three ranges, plus reverse range.Reference

PTO & Hydraulics

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Dimensions

Wheelbase286 cmReference

Weight8700 kgReference

Front tire23.1R26Reference

Rear tire23.1R26Reference

Ag front23.1R26Reference

Ag rear23.1R26Reference

Length649 cmReference

Width246 cmReference

Height (exhaust)336 cmReference

Ground clearance44 cmReference

Front tread185 cmReference

Rear tread185 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
