Tractor · Unverified

XTZ XTZ-17221-09

Name: XTZ XTZ-17221-09
Brand: XTZ

XTZ XTZ-17221-09 — Four-wheel Drive (4WD) tractor · 180 hp. Reference specifications; pending source verification.

The XTZ XTZ-17221-09 is a tractor with an output of 180 hp, categorising it among the more powerful models in its class. It features a 6-cylinder diesel liquid-cooled engine, which drives four-wheel drive via a 16-speed gearbox. The tractor's listed weight is 8618 kg, and it is designed for use on areas of approximately 600–1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

180 hp

Weight

8618 kg

Catalogue coverage

Variants represented

Richest spec table

34 rows

Recorded power

180 hp

Recorded weight

8618 kg

Transmissions

16-speed

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerXTZReference

Four-wheel Drive (4WD) tractorReference

Built in Kharkiv, UkraineReference

Four-wheel driveReference

Articulated power steeringReference

Cab standard with air-conditioning.Reference

Engine

YaMZ 11.2L 6-cyl dieselReference

Engine134.2 kWReference

YaMZ 236Reference

dieselReference

6-cylinderReference

liquid-cooled V-6Reference

Displacement11.2 LReference

Bore/Stroke130 x 140 mmReference

Power134.2 kWReference

Rated RPM2100Reference

Starter typeelectricReference

Transmission

16-speedReference

Gears16 forward and 8 reverseReference

Clutchdry discReference

PTO & Hydraulics

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Dimensions

Wheelbase286 cmReference

Weight8618 kgReference

Front tire23.1R26Reference

Rear tire23.1R26Reference

Ag front23.1R26Reference

Ag rear23.1R26Reference

Length640 cmReference

Width246 cmReference

Height (cab)325 cmReference

Ground clearance44 cmReference

Front tread185 cmReference

Rear tread185 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
