Tractor · Unverified
XTZ XTZ-3521
XTZ XTZ-3521 — Compact Utility tractor · 35 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Weight
2280 kg
Hover a source tag to verify
Overview
ManufacturerXTZReference
Compact Utility tractorReference
Built in Kharkiv, UkraineReference
Two-wheel driveReference
Power steeringReference
Cab standard, heater available.Reference
Engine
Deutz 1.7L 2-cyl dieselReference
Fuel tank50.0 LReference
Engine26.1 kWReference
Deutz F2L511Reference
dieselReference
2-cylinderReference
air-cooledReference
Displacement1.7 LReference
Bore/Stroke100 x 105 mmReference
Power26.1 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
14-speedReference
Gears14 forward and 12 reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear PTOindependentReference
Rear PTO Type540Reference
Dimensions
Wheelbase191 cmReference
Weight2280 kgReference
Front tire6.5R16Reference
Rear tire11.2-28Reference
Ag front6.5R16Reference
Ag rear11.2-28Reference
Length314 cmReference
Width148 cmReference
Height260 cmReference
Ground clearance51 cmReference
Front tread139 to 160 cmReference
Rear tread139 to 160 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
