The XTZ XTZ-5020 is a tractor model with a rated output of 50 hp — making it one of the more compact options in its class. It is powered by a 4-cylinder diesel air-cooled engine, driving through four-wheel drive with a 20-speed gearbox. Listed weight is 2980 kg, and it is aimed at jobs of around up to 200 ac. The available specification table below shows both UK and US units.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
2980 kg
Catalogue coverage
Variants represented
2
Richest spec table
33 rows
Recorded power
50 hp
Recorded weight
2980 kg
Transmissions
20-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerXTZReference
Compact Utility tractorReference
Built in Kharkiv, UkraineReference
Four-wheel driveReference
Cab standard, heater available.Reference
Engine
VMTZ 4.2L 4-cyl dieselReference
Fuel tank95.0 LReference
Engine37.3 kWReference
VMTZ D-144Reference
dieselReference
4-cylinderReference
air-cooledReference
Displacement4.2 LReference
Bore/Stroke105 x 120 mmReference
Power37.3 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
20-speedReference
Gears20 forward and 4 reverseReference
PTO & Hydraulics
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase217 cmReference
Weight2980 kgReference
Front tire11.2R20Reference
Rear tire12.4R28Reference
Ag front11.2R20Reference
Ag rear12.4R28Reference
Length366 cmReference
Width212 cmReference
Height264 cmReference
Ground clearance32 cmReference
Front tread139 to 180 cmReference
Rear tread139 to 180 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
