Tractor · 2014Unverified
Yanmar 221
Yanmar 221 — SA Series · 22 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
22 hp
Weight
697 kg
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Sub-Compact Utility tractorReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post foldable ROPS.Reference
Engine
Yanmar 1.0L 3-cyl dieselReference
Engine (gross)16.0 kWReference
Engine (net)14.5 kWReference
Yanmar 3TNM74FReference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.0 LReference
Bore/Stroke74 x 77 mmReference
EmissionsTier 4Reference
Power (net)14.5 kWReference
Power (gross)16.0 kWReference
Rated RPM3200Reference
Torque53.4 NmReference
StarterelectricReference
Starter volts12Reference
Oil capacity2.9 LReference
Coolant capacity2.8 LReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
Oil capacity15.5 LReference
PTO & Hydraulics
PTO (claimed)11.6 kWReference
Typeopen centerReference
Pressure130.4 barReference
Pump flow16.3 lpmReference
Steering flow14.0 lpmReference
Rear Type1 (limited)Reference
Rear lift (at 24"/610mm)299 kgReference
Rear PTOindependentReference
ClutchhydraulicReference
Rear PTO Type540 (1.375)Reference
Engine RPM554@3200Reference
Mid PTOindependentReference
Clutch2057:3200Reference
Mid PTO Type2000 (1.0)Reference
Capacities
Fuel22.7 LReference
Front axle3.0 LReference
Dimensions
Wheelbase147 cmReference
Weight697 kgReference
Lawn/turf front18x8.50-10Reference
Lawn/turf rear26x12.0-12Reference
Industrial front18x8.50-10Reference
Industrial rear26x12.0-12Reference
Length259 cmReference
Width120 cmReference
Ground clearance16 cmReference
Front tread89 cmReference
Rear tread89 cmReference
Steering wheel129 cmReference
Yanmar 221 attachments
60" mid-mount mower deckReference
front-end loaderReference
Electrical
GroundnegativeReference
Battery CCA540Reference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
Front-end loaderReference
60" Mower deck
Typemid-mount YanmarReference
Cutting width152 cmReference
Yanmar 221 Height
ROPS209 cmReference
ROPS168 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
