Tractor · 2001Unverified
Yanmar AF650
Yanmar AF650 — AF600 Series · 50 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
2214 kg
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Four-wheel driveReference
Power steeringReference
Mechanical wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Yanmar 2.8L 4-cyl dieselReference
Fuel tank65.1 LReference
Engine37.3 kWReference
Yanmar 4TNV94Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.8 LReference
Power37.3 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
18-speed power shuttleReference
Typepower shuttleReference
Gears18 forward and reverseReference
Clutchhydraulic wet discReference
PTO & Hydraulics
Rear TypeIReference
Controlposition controlReference
Rear lift1702 kgReference
Rear PTOindependentReference
Rear PTO Type564/756/1073 (1.375)Reference
Dimensions
Wheelbase189 cmReference
Weight2214 kgReference
Front tire8-15Reference
Rear tire13.6-28Reference
Standard tires (ag)Front: 8-15. Rear: 13.6-28Reference
Length346 cmReference
Width160 cmReference
Height246 cmReference
Ground clearance35 cmReference
Front tread119 to 148 cmReference
Rear tread127 to 161 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH110Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
