Tractor · 2001Unverified
Yanmar AF880
Yanmar AF880 — AF800 Series · 80 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
80 hp
Weight
3400 kg
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Yanmar 4.4L 4-cyl dieselReference
Fuel tank120.0 LReference
Engine59.7 kWReference
Yanmar 4TNV106Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Power59.7 kWReference
Fuel systemdirect injectionReference
Rated RPM2400Reference
StarterelectricReference
Starter volts12Reference
Transmission
18-speed power shuttleReference
Typepower shuttleReference
Gears18 forward and reverseReference
Clutchhydraulic wet discReference
PTO & Hydraulics
Rear TypeII/IReference
Controlposition and draft controlReference
Rear lift3399 kgReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type561/760/986Reference
Dimensions
Wheelbase230 cmReference
Weight3400 kgReference
Front tire9.5-24Reference
Rear tire13.6-38Reference
Standard tires (ag)Front: 9.5-24. Rear: 13.6-38Reference
Length402 cmReference
Width181 cmReference
Height271 cmReference
Front tread121 to 185 cmReference
Rear tread121 to 182 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
