Tractor · 2002Unverified

Yanmar EF326

Name: Yanmar EF326
Brand: Yanmar

Yanmar EF326 — EF300 Series · 26 hp. Reference specifications; pending source verification.

The Yanmar EF326 is a tractor rated at approximately 26 hp, categorising it within the lighter capacity range for its class. It was manufactured between 2002 and 2004. The model features a 3-cylinder diesel liquid-cooled engine, paired with four-wheel drive and a powershift transmission. Its operating weight is listed as 2954 to 3351 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

26 hp

Weight

2954 to 3351 pounds

Catalogue coverage

Variants represented

Richest spec table

46 rows

Recorded power

26 hp

Recorded weight

1339 kg

Transmissions

16-speed four-speed power shift

Production years

2002-2004

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerYanmarReference

Compact Utility tractorReference

Four-wheel driveReference

Variants

EF326QCabReference

Engine

Yanmar 1.5L 3-cyl dieselReference

Fuel tank26.9 LReference

Engine19.1 kWReference

Yanmar 3TNV84Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke84 x 90 mmReference

Power19.1 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

16-speed four-speed power shiftReference

Typefour-speed power shiftReference

Gears16 forward and reverseReference

Four power shift gears in four ranges, with shuttle.Reference

PTO & Hydraulics

Rear TypeJIS1Reference

Rear lift1500 kgReference

Rear PTO540 (1.375)Reference

Engine RPM547@2600Reference

Engine RPM755@2600Reference

Engine RPM955@2600Reference

Engine RPM1248@2600Reference

Engine RPM-600@2600Reference

Dimensions

Wheelbase164 cmReference

Weight2954 to 3351 poundsReference

Front tire7-16Reference

Rear tire11.2-24Reference

Standard tires (ag)Front: 7-16. Rear: 11.2-24Reference

Length306 cmReference

Width138 cmReference

Height (ROPS)195 cmReference

Height (cab)197 cmReference

ROPS Weight1339 kgReference

Cab Weight1520 kgReference

Ground clearance31 cmReference

Front tread109 cmReference

Rear tread105 to 135 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Speeds

Reverse speeds are 5% slower than forward.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
