Tractor · 2009Unverified
Yanmar EF453
Yanmar EF453 — EF Series · 45 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Weight
1549 kg
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS.Reference
Engine
Yanmar 2.2L 4-cyl dieselReference
Fuel tank40.1 LReference
Engine (gross)33.6 kWReference
Yanmar 4TNV88Reference
dieselReference
4-cylinderReference
liquid-cooled inlineReference
Displacement2.2 LReference
Bore/Stroke88 x 90 mmReference
Power (gross)33.6 kWReference
Rated RPM2700Reference
StarterelectricReference
Starter volts12Reference
Transmission
9-speed synch shuttleReference
Typesynch shuttleReference
Gears9 forward and reverseReference
Clutch260mm dry discReference
Three gears in three ranges with shuttle shift.Reference
PTO & Hydraulics
Rear TypeIReference
Rear lift (at ends)1349 kgReference
Rear PTO Type540 (1.375)Reference
Engine RPM547@2700Reference
Engine RPM741@2700Reference
Dimensions
Wheelbase183 cmReference
Weight1549 kgReference
Front tire8-18Reference
Rear tire13.6-26Reference
Ag front8-18Reference
Ag rear13.6-26Reference
Length323 cmReference
Width160 cmReference
Height246 cmReference
Ground clearance35 cmReference
Speeds
With 13.6-26 rear tires. Reverse speeds are 3% faster than forward.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
