Tractor · 1989Unverified
Yanmar F-7 Forte
Yanmar F-7 Forte — Compact Utility tractor · 17 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
17 hp
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockmechanical rearReference
Open operator station.Reference
Variants
F-7Hhigh-clearanceReference
Engine
1.0L 3-cyl dieselReference
Engine12.3 kWReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.0 LReference
Power12.3 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
12-speedReference
Gears12 forward and 4 reverseReference
Three speeds, plus reverse, in two ranges with additional creeper range.Reference
PTO & Hydraulics
Rear PTO Type540/750/1000Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Dimensions
Length325 cmReference
Width145 cmReference
Height130 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
