Tractor · 1983Unverified
Yanmar F20
Yanmar F20 — Super Forte Series · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Weight
1095 kg
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Open operator station.Reference
Variants
F202WD gearReference
F20D4WD gearReference
FX202WD power shiftReference
FX20D4WD power shiftReference
Engine
Yanmar 1.4L 3-cyl dieselReference
Engine14.9 kWReference
Yanmar 3TN82Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.4 LReference
Bore/Stroke82 x 86 mmReference
Power14.9 kWReference
Starter volts12Reference
Transmission
9-speed gearReference
TypegearReference
Gears9 forward and 3 reverseReference
Clutchdry discReference
Three gears, plus reverse, in three ranges.Reference
PTO & Hydraulics
Rear PTO Type540/650/900/1250Reference
Dimensions
Weight1095 kgReference
Length287 cmReference
Width124 cmReference
Height175 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
