Tractor · 1987Unverified

Yanmar F265

Name: Yanmar F265
Brand: Yanmar

Yanmar F265 — Compact Utility tractor · 26 hp. Reference specifications; pending source verification.

The Yanmar F265 is a tractor model with a rating of approximately 26 hp, positioning it at the lighter end of its class. Production of the F265 took place from 1987 to 1992. It features a 3-cylinder diesel liquid-cooled engine, paired with four-wheel drive and a powershift transmission. The tractor has an operating weight of 2249 to 2414 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

26 hp

Weight

2249 to 2414 pounds

Catalogue coverage

Variants represented

Richest spec table

55 rows

Recorded power

26 hp

Recorded weight

1020 kg

Transmissions

9-speed gear

Production years

1987-1992

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerYanmarReference

Compact Utility tractorReference

Two- or four-wheel driveReference

Open operator station.Reference

Variants

F2652WD gearReference

F265D4WD gearReference

FX2652WD power shiftReference

FX265D4WD power shiftReference

Engine

Yanmar 1.5L 3-cyl dieselReference

Fuel tank25.0 LReference

Engine19.1 kWReference

Yanmar 3TNB84Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke84 x 88 mmReference

Power19.1 kWReference

Rated RPM2500Reference

Starter volts12Reference

Transmission

9-speed gearReference

18-speed creeperReference

TypegearReference

Gears9 forward and 3 reverseReference

Three gears in three ranges.Reference

TypecreeperReference

Gears18 forward and 6 reverseReference

PTO & Hydraulics

Rear TypeJIS1Reference

Rear PTO Type540 (1.375)Reference

Engine RPM574@2500Reference

Engine RPM698@2500Reference

Engine RPM958@2500Reference

Engine RPM1293@2500Reference

Dimensions

2WD Wheelbase151 cmReference

4WD Wheelbase152 cmReference

Weight2249 to 2414 poundsReference

Front tire5.00-15Reference

2WD Rear tire12.4-24Reference

2WD Standard tires (ag)Front: 5.00-15. Rear: 12.4-24Reference

4WD Standard tires (ag)Front: 7-16. Rear: 12.4-24Reference

Length286 cmReference

Width140 cmReference

Height151 cmReference

2WD Weight1020 kgReference

4WD Weight1094 kgReference

2WD Ground clearance36 cmReference

4WD Ground clearance32 cmReference

2WD Front tread99 cmReference

4WD Front tread152 cmReference

Rear tread107 to 137 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps16Reference

Battery volts12Reference

Battery AH75Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
