The Yanmar F320 is a tractor with a rated power of 32 hp, which places it at the lighter end of its class. It is powered by a 3-cylinder diesel engine, paired with a 9-speed gearbox. It has a listed operating weight of 1350 kg, and it suits operations of up to 200 ac. Available dimensions and performance figures follow in both unit systems.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
32 hp
Weight
1350 kg
Catalogue coverage
Variants represented
2
Richest spec table
26 rows
Recorded power
32 hp
Recorded weight
1350 kg
Transmissions
9-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Engine
Yanmar 1.5L 3-cyl dieselReference
Fuel tank32.2 LReference
Engine23.9 kWReference
YanmarReference
dieselReference
3-cylinderReference
Displacement1.5 LReference
Bore/Stroke84 x 90 mmReference
Power23.9 kWReference
Transmission
9-speedReference
TransmissionsynchromeshReference
Gears9 forward and 3 reverseReference
PTO & Hydraulics
Rear TypeIReference
Rear lift1250 kgReference
Rear PTOliveReference
Rear PTO Type540Reference
Dimensions
Wheelbase171 cmReference
Weight1350 kgReference
Front tire7-14Reference
Rear tire12.4-24Reference
Ag front7-14Reference
Ag rear12.4-24Reference
Length327 cmReference
Width145 cmReference
Height233 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
