Tractor · 1989Unverified
Yanmar F395
Yanmar F395 — Power Forte Series · 35 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Weight
1789 kg
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Utility tractorReference
Four-wheel driveReference
Power steeringReference
Four-post ROPS. Cab optional.Reference
Engine
Yanmar 1.9L 4-cyl dieselReference
Fuel tank50.0 LReference
Engine28.7 kWReference
Yanmar 4TN84Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.9 LReference
Bore/Stroke84 x 86 mmReference
Power28.7 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity5.3 LReference
Coolant capacity6.0 LReference
Transmission
9-speedReference
24-speed shuttleReference
Gears9 forward and 3 reverseReference
Three gears, plus reverse, in three ranges. Additional creeper doubles the number of available gears.Reference
TypeshuttleReference
Gears24 forward and reverseReference
ClutchReverse speeds are 8% slower than forward.Reference
PTO & Hydraulics
PTO (claimed)26.0 kWReference
Pump flow31.4 lpmReference
Rear TypeJIS1Reference
Rear PTO Type540 (1.375)Reference
Engine RPM549@2600Reference
Engine RPM676@2600Reference
Engine RPM798@2600Reference
Engine RPM1009@2600Reference
Dimensions
Wheelbase186 cmReference
Weight1789 kgReference
Front tire8-18Reference
Rear tire12.4-28Reference
Standard tires (ag)Front: 8-18. Rear: 12.4-28Reference
Length350 cmReference
Width160 cmReference
Height234 cmReference
Ground clearance34 cmReference
Front tread133 cmReference
Rear tread124 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40Reference
Battery volts12Reference
Battery AH110Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
