The Yanmar FV-250 is a tractor with a rated output of 25 hp — making it one of the more compact options in its class. The FV-250 was produced from 1991 to 1998. It is powered by a 3-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a powershift transmission. It is aimed at jobs of around up to 200 ac. The available specification table below shows both UK and US units.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Catalogue coverage
Variants represented
2
Richest spec table
22 rows
Recorded power
25 hp
Transmissions
24-speed four-speed power shift
Production years
1991-1998
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Compact Utility tractorReference
Four-wheel driveReference
Open operator station.Reference
Engine
Yanmar 1.5L 3-cyl dieselReference
Engine18.4 kWReference
Yanmar 3TNV84Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke84 x 90 mmReference
Power18.4 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speed four-speed power shiftReference
Typefour-speed power shiftReference
Gears24 forward and reverseReference
Four power shift gears in three, ranges, plus additional creeper range.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
