The Yanmar FV-330 is a tractor with a rated power output of 33 hp, positioning it at the lower end of its class. This model was manufactured from 1992 to 1998. It is equipped with a 3-cylinder diesel liquid-cooled engine and a four-wheel drive system paired with a powershift transmission. The tractor is suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
33 hp
Catalogue coverage
Variants represented
2
Richest spec table
22 rows
Recorded power
33 hp
Transmissions
24-speed four-speed power shift
Production years
1992-1998
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Compact Utility tractorReference
Four-wheel driveReference
Open operator station.Reference
Engine
Yanmar 1.5L 3-cyl dieselReference
Engine24.3 kWReference
Yanmar 3TNV86Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke86 x 90 mmReference
Power24.3 kWReference
Rated RPM2750Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speed four-speed power shiftReference
Typefour-speed power shiftReference
Gears24 forward and reverseReference
Four power shift gears in three, ranges, plus additional creeper range.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
