The Yanmar FV-430 is a tractor with a rated output of 42 hp, making it a relatively compact model in its class. Manufactured from 1991 to 1998, this model features a 3-cylinder diesel liquid-cooled engine, which drives a four-wheel drive system via a powershift transmission. Its capabilities are suited to tasks on land areas of approximately up to 200 ac.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
42 hp
Catalogue coverage
Variants represented
2
Richest spec table
22 rows
Recorded power
42 hp
Transmissions
24-speed four-speed power shift
Production years
1991-1998
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Compact Utility tractorReference
Four-wheel driveReference
Open operator station.Reference
Engine
Yanmar 1.5L 3-cyl dieselReference
Engine31.6 kWReference
Yanmar 3TNV86Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke86 x 90 mmReference
Power31.6 kWReference
Rated RPM2700Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speed four-speed power shiftReference
Typefour-speed power shiftReference
Gears24 forward and reverseReference
Four power shift gears in three, ranges, plus additional creeper range.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
