Tractor · 1987Unverified
Yanmar FX255
Yanmar FX255 — Compact Utility tractor · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
2205 to 2370 pounds
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Open operator station.Reference
Variants
F2552WD gearReference
F255D4WD gearReference
FX2552WD power shiftReference
FX255D4WD power shiftReference
Engine
Yanmar 1.5L 3-cyl dieselReference
Fuel tank25.0 LReference
Engine18.4 kWReference
Yanmar 3TNB84Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke84 x 88 mmReference
Power18.4 kWReference
Rated RPM2500Reference
Starter volts12Reference
Transmission
9-speed partial power shiftReference
18-speed creeperReference
Typepartial power shiftReference
Gears9 forward and 3 reverseReference
Three gears, plus reverse, in three ranges.Reference
TypecreeperReference
Gears18 forward and 6 reverseReference
PTO & Hydraulics
Rear TypeJIS1Reference
Rear PTO Type540 (1.375)Reference
Engine RPM574@2500Reference
Engine RPM698@2500Reference
Engine RPM956@2500Reference
Engine RPM1293@2500Reference
Dimensions
2WD Wheelbase151 cmReference
4WD Wheelbase152 cmReference
Weight2205 to 2370 poundsReference
Front tire5.00-15Reference
2WD Rear tire11.2-24Reference
2WD Standard tires (ag)Front: 5.00-15. Rear: 11.2-24Reference
4WD Standard tires (ag)Front: 7-16. Rear: 11.2-24Reference
Length283 cmReference
Width132 cmReference
Height150 cmReference
2WD Weight1000 kgReference
4WD Weight1075 kgReference
2WD Ground clearance34 cmReference
4WD Ground clearance32 cmReference
2WD Front tread99 cmReference
4WD Front tread105 cmReference
Rear tread102 to 132 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps16Reference
Battery volts12Reference
Battery AH75Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
