The Yanmar FX26 is a compact tractor with a rated output of 26 hp, one of the lower power options in its class. Produced from 1983 to 1987, the FX26 features a 4-cylinder diesel liquid-cooled engine driving four-wheel drive via a powershift transmission. Its intended application is for jobs covering areas of approximately 200 acres or less.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
26 hp
Catalogue coverage
Variants represented
2
Richest spec table
26 rows
Recorded power
26 hp
Transmissions
12-speed four-speed power shift
Production years
1983-1987
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Differential lockmechanical rearReference
Open operator station.Reference
Variants
FX262WDReference
FX26D4WDReference
Engine
Yanmar 1.6L 4-cyl dieselReference
Engine19.4 kWReference
Yanmar 4TNA78Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke78 x 86 mmReference
Power19.4 kWReference
Starter volts12Reference
Transmission
12-speed four-speed power shiftReference
Typefour-speed power shiftReference
Gears12 forward and 6 reverseReference
Four power-shift gears, plus two reverse, in three ranges.Reference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
FX26 Serial Numbers
Location:Left side of the tractor on the transmission housing.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
