Tractor · 1987Unverified

Yanmar FX305

Name: Yanmar FX305
Brand: Yanmar

Yanmar FX305 — Super Forte Series · 30 hp. Reference specifications; pending source verification.

The Yanmar FX305 is a tractor rated at approximately 30 hp, positioning it at the lower end of its class. Produced from 1987 to 1992, this tractor is equipped with a 4-cylinder diesel liquid-cooled engine and four-wheel drive, paired with a powershift transmission. Its operating weight ranges from 2976 to 3241 pounds, and it is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

30 hp

Weight

2976 to 3241 pounds

Catalogue coverage

Variants represented

Richest spec table

39 rows

Recorded power

30 hp

Recorded weight

1349 kg

Transmissions

12-speed four-speed power shift

Production years

1987-1992

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerYanmarReference

Compact Utility tractorReference

Two- or four-wheel driveReference

Open operator station.Reference

Variants

FX305D4WDReference

Engine

Yanmar 1.6L 4-cyl dieselReference

Engine22.4 kWReference

Yanmar 4TNA78Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement1.6 LReference

Bore/Stroke78 x 86 mmReference

Power22.4 kWReference

Starter volts12Reference

Transmission

12-speed four-speed power shiftReference

Typefour-speed power shiftReference

Gears12 forward and 6 reverseReference

Four power-shift gears, plus two reverse, in three ranges.Reference

PTO & Hydraulics

Rear PTO Type540 (1.375)Reference

Dimensions

2WD Wheelbase183 cmReference

4WD Wheelbase183 cmReference

Weight2976 to 3241 poundsReference

Front tire6.00-16Reference

2WD Rear tire13.6-26Reference

2WD Standard tires (ag)Front: 6.00-16. Rear: 13.6-26Reference

4WD Standard tires (ag)Front: 8-18. Rear: 13.6-26Reference

Length311 cmReference

Width148 cmReference

Height143 cmReference

2WD Weight1349 kgReference

4WD Weight1470 kgReference

2WD Ground clearance38 cmReference

4WD Ground clearance33 cmReference

2WD Front tread114 cmReference

4WD Front tread120 cmReference

Rear tread115 to 150 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
