The Yanmar Ke-170H is a compact tractor with a rated power output of 17 hp. It is equipped with a 3-cylinder diesel liquid-cooled engine, driving through four-wheel drive via a hydrostatic transmission. The tractor's listed weight is 747 kg, and it is designed for operations on land areas of up to 200 ac.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
17 hp
Weight
747 kg
Catalogue coverage
Variants represented
2
Richest spec table
28 rows
Recorded power
17 hp
Recorded weight
747 kg
Transmissions
hydrostatic
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Compact Utility tractorReference
Four-wheel driveReference
Engine
Yanmar 3-cyl dieselReference
Fuel tank22.0 LReference
Engine12.7 kWReference
YanmarReference
dieselReference
3-cylinderReference
liquid-cooledReference
Power12.7 kWReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Rear TypeIReference
Rear lift519 kgReference
Rear PTOliveReference
Rear PTO Type540Reference
Dimensions
Wheelbase147 cmReference
Weight747 kgReference
Front tire5.00-12Reference
Rear tire9.5-16Reference
Ag front5.00-12Reference
Ag rear9.5-16Reference
Length271 cmReference
Width119 cmReference
Height219 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
