Tractor · 2012Unverified

Yanmar Lx410

Name: Yanmar Lx410
Brand: Yanmar

Yanmar Lx410 — Lx Series · 41 hp. Reference specifications; pending source verification.

The Yanmar Lx410 is a tractor with a rated power of 41 hp, categorising it as a lighter model within its class. It was produced in 2012 and features a 4-cylinder diesel liquid-cooled engine. The Lx410 is equipped with four-wheel drive and a 12-speed gearbox, and its listed operating weight is 1626 kg. It is suitable for use on areas up to 200 ac.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

41 hp

Max power

41 hp

Weight

1626 kg

Catalogue coverage

Variants represented

Richest spec table

98 rows

Recorded power

41 hp

Recorded weight

1626 kg

Transmissions

12-speed power shuttle

Production years

2012-2012

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerYanmarReference

Compact Utility tractorReference

Four-wheel driveReference

Steeringhydraulic powerReference

Wet disc brakesReference

Two-post ROPS.Reference

Variants

Lx410shuttleReference

Lx4100hydroReference

Engine

Yanmar 2.2L 4-cyl dieselReference

Fuel tank45.0 LReference

Engine (gross)30.6 kWReference

YanmarReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.2 LReference

Bore/Stroke88 x 90 mmReference

Power (gross)30.6 kWReference

Fuel systemdirect injectionReference

Air cleanerdual dry elementReference

Rated RPM2700Reference

StarterelectricReference

Starter volts12Reference

Oil capacity5.3 LReference

Coolant capacity4.8 LReference

Fuel TypedieselReference

No of Cylinders4 cylinderReference

Rated engine speed2,700 RPMReference

Bore and stroke3.465x3.543 inchesReference

Cooling systemliquid-cooledReference

Transmission

12-speed power shuttleReference

TransmissionHydraReverserReference

Typepower shuttleReference

Gears12 forward and reverseReference

Clutchwet discReference

Oil capacity32.2 LReference

Transmission TypePower ShuttleReference

forward and reverse optionsPower Shuttle : 12 F and 12 RReference

Wheel Drive4WDReference

PTO & Hydraulics

Typeopen centerReference

Valves2 to 3Reference

Pump flow34.1 lpmReference

Steering flow25.7 lpmReference

Rear Type1Reference

Controlposition controlReference

Rear lift (at 24"/610mm)1251 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540Reference

Dimensions

Wheelbase189 cmReference

Weight1626 kgReference

Front tire8-16Reference

Rear tire14.9-24Reference

Weight612 kgReference

Ag front8-16Reference

Ag rear14.9-24Reference

Lawn/turf front27x10.5-15Reference

Lawn/turf rear44x18-20Reference

Lawn/turf front27/12LL-15Reference

Lawn/turf rear22.5LL-16.1Reference

Industrial front10-16.5Reference

Industrial rear17.5LL-24Reference

Length314 cmReference

Width176 cmReference

Ground clearance38 cmReference

Yanmar Lx410 attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

Yanmar CB85 Backhoe

Backhoe typeYanmar CB85 BackhoeReference

Digging depth261 cmReference

2-Foot flat digging depth259 cmReference

Reach from pivot360 cmReference

Loading height220 cmReference

Bucket Rotation180°Reference

Swing Arc180°Reference

Bucket force1691 kgReference

Dipperstick force1104 kgReference

General

Make & ModelYanmarReference

Rollover protective structureTwo-post ROPS.Reference

Capacities

Capacity133.6 ciReference

Crankcase oil volume5.62 qtsReference

Power

Max Power41 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Steering & brakes

Brakeswet discReference

Steering typehydraulic powerReference

Hydraulics

Hydraulics Typeopen centerReference

Remote Valves2 to 3 ValvesReference

Steering & Implements flow6.8 gpm (9 gpm)Reference

Rear Hitch category (SAE designation)Category 1Reference

Rear Hitch Sensing Typeposition controlReference

Dimensions & weight

Overall Length315 cmReference

Overall Width176.5 cmReference

Overall weight1,626.1 kgReference

Operator station

Seat SuspensionTRUEReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
