Tractor · 2025Unverified
Yanmar SA222
Yanmar SA222 — SA Series · 22 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
22 hp
Weight
1631 to 2121 pounds
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Sub-Compact Utility tractorReference
Built in Torbali, TurkeyReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional with heat.Reference
Engine
Yanmar 0.9L 3-cyl dieselReference
Engine (gross)16.1 kWReference
Yanmar 3TNM72Reference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement0.9 LReference
Bore/Stroke72 x 74 mmReference
Power (gross)16.1 kWReference
Rated RPM3000Reference
Torque52.6 NmReference
StarterelectricReference
Starter volts12Reference
Oil capacity2.9 LReference
Coolant capacity3.3 LReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
Oil capacity15.5 LReference
PTO & Hydraulics
PTO (claimed)11.0 kWReference
Typeopen centerReference
Pressure130.0 barReference
Mid valves2Reference
Pump flow15.1 lpmReference
Steering flow13.2 lpmReference
Rear TypeI (Limited)Reference
Rear lift (at 24"/610mm)299 kgReference
Rear PTOindependentReference
Clutch540:3120Reference
Rear PTO Type540 (1.375)Reference
Mid PTOindependentReference
Mid PTO TypeSAE 16/32Reference
Engine RPM2000@3111Reference
Capacities
Fuel23.1 LReference
Front axle3.0 LReference
ROPS Max capacity1475 kgReference
Cab Max capacity1700 kgReference
Tow capacity699 kgReference
Tow capacity1599 kgReference
Dimensions
Wheelbase147 cmReference
Weight1631 to 2121 poundsReference
Lawn/turf front18x8.50-10Reference
Lawn/turf rear26x12.0-12Reference
Industrial front18x8.50-10Reference
Industrial rear26x12.0-12Reference
Length270 cmReference
Width119 cmReference
Height (ROPS)227 cmReference
Height (cab)203 cmReference
Ground clearance24 cmReference
Front tread89 cmReference
Rear tread89 cmReference
ROPS739 kgReference
Cab962 kgReference
Max front axle699 kgReference
Max rear axle1000 kgReference
SA222 Serial Numbers
Location:Serial number plate on the front right of the tractor frame, above the front axle.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
