Tractor · 1984Unverified
Yanmar YM140
Yanmar YM140 — Sub-Compact Utility tractor · 11 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
11 hp
Weight
1096 to 1190 pounds
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Sub-Compact Utility tractorReference
Original price was $7000 in 1992Reference
Two- or four-wheel driveReference
Mechanical shoe brakesReference
Open operator station. Two-post ROPS available.Reference
Variants
YM1402WD gear shiftReference
YM140D4WD gear shiftReference
YM1472WD power shiftReference
YM147D4WD power shiftReference
Engine
Yanmar 0.6L 2-cyl dieselReference
Fuel tank15.9 LReference
Engine10.4 kWReference
Yanmar 2T75UAReference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement0.6 LReference
Bore/Stroke75 x 72 mmReference
Power10.4 kWReference
Rated RPM2600Reference
Starter volts12Reference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 3 reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)8.1 kWReference
Typeopen centerReference
Pump flow12.9 lpmReference
Rear TypeIReference
Rear lift (at ends)400 kgReference
Rear lift (at 24"/610mm)350 kgReference
Rear PTOtransmissionReference
Clutchoverrunning clutchReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2356Reference
Front PTOindependentReference
ClutchelectricReference
Dimensions
Wheelbase134 cmReference
Weight1096 to 1190 poundsReference
Front tire4.00x12Reference
2WD Rear tire8x16Reference
2WD Standard tires (ag)Front: 4.00x12. Rear: 8x16Reference
2WD Standard tires (ag)Front: 6.9x9. Rear: 8.3x16Reference
4WD Standard tires (ag)Front: 5x12. Rear: 8x16Reference
4WD Standard tires (ag)Front: 5x12. Rear: 8.3x16Reference
Lawn/turf front20.5x8-10Reference
Lawn/turf rear29x12.00-15Reference
Length247 cmReference
2WD Width97 cmReference
4WD Width99 cmReference
2WD Height (steering wheel)122 cmReference
4WD Height (steering wheel)123 cmReference
2WD Weight497 kgReference
4WD Weight539 kgReference
Clearance (drawbar)19 cmReference
2WD Front tread81 cmReference
4WD Front tread81 cmReference
Rear tread74/80/85 cmReference
Yanmar YM140 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
