Tractor · 1979Unverified
Yanmar YM1510
Yanmar YM1510 — Compact Utility tractor · 15 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
15 hp
Weight
635 kg
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Open operator station.Reference
Variants
YM15102WDReference
YM1510D4WDReference
Engine
Yanmar 0.9L 3-cyl dieselReference
Engine11.2 kWReference
Yanmar 3T72SAReference
dieselReference
3-cylinder 6-valveReference
liquid-cooledReference
Displacement0.9 LReference
Bore/Stroke72 x 72 mmReference
Power11.2 kWReference
Starter volts12Reference
Dimensions
Weight635 kgReference
Length213 cmReference
Width99 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Transmission
Transmissionpower shiftReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
