The Yanmar YM1602 is a tractor model with an engine rating of approximately 16 hp, positioning it at the lighter end of its class. This model was in production from 1982 to 1983. It features a 3-cylinder diesel liquid-cooled engine, paired with four-wheel drive, and has a listed operating weight of 689 kg. It is capable of handling operations up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
689 kg
Catalogue coverage
Variants represented
2
Richest spec table
23 rows
Recorded power
16 hp
Recorded weight
689 kg
Transmissions
gear
Production years
1982-1983
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Open operator station.Reference
Variants
YM16022WDReference
YM1602D4WDReference
Engine
Yanmar 1.0L 3-cyl dieselReference
Engine11.9 kWReference
Yanmar 3T75UReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.0 LReference
Bore/Stroke75 x 75 mmReference
Power11.9 kWReference
Starter volts12Reference
Dimensions
Weight689 kgReference
Length256 cmReference
Width104 cmReference
Height175 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Transmission
TransmissiongearReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
